Soflex?BT24452(F Grade DMD epoxy prepreg fabric)

Insulation level: 155C ° C

Soflex? BT24452 is a flexible composite made of a polyester film polyester fiber nonwoven soft composite impregnated with an F-grade epoxy resin and semi-cured.


      Basic characteristics

      ? Good heat resistance and good dielectric and mechanical properties

      ? No low molecular weight volatiles are produced during the baking process

      ? Can be cured at medium temperatures to form a stable insulation structure that shrinks and can firmly adhere to metal surfaces

      ? Compatible with most adhesives, resins, and paints

Product Information

  • · UL number : 無(wú)
  • · Temperature resistance grade : 155C°
  • · certificates : UL, RoHS, REACH, MSDS
  • · system certification : ISO9001，ISO14001，IATF16949
  • · standard width : 1000mm
  • · Packaging method : 紙箱
  • · Free sample collection : A4
  • · brand : Soflex?

    • Product specifications

    Soflex? BT24452 is a flexible composite material made of polyester film polyester fiber nonwoven soft composite material impregnated with class F epoxy resin after semi-curing. It is suitable for low voltage interlayer insulation of cast-in epoxy transformers, as well as inter-slot insulation and turn-to-turn insulation of F-grade motors and electrical appliances.


    Thickness (mm)

    Thickness (mm)

    Optional width (mm)

    Quantitative (g/m 2)

    Quantitative allowable deviation (g/m 2)

    0.15

    1000

    2.5~1500

    130

    ±20

    0.18

    1000

    2.5~1500

    145

    ±30

    0.20

    1000

    2.5~1500

    180

    ±30

    0.25

    1000

    2.5~1500

    260

    ±35

    0.25

    1000

    2.5~1500

    310

    ±40

    0.40

    1000

    2.5~1500

    460

    ±60


    Soflex? BT24452 tubing cores with a 3-inch inside diameter can be supplied in full rolls or cut into strip trays or sheets in lengths to suit the customer's requirements.


    Other information

    Product application

    suitable for low voltage interlayer insulation of epoxy cast-in transformers, and inter-slot insulation and inter-turn insulation of F-class motors and electrical appliances.



    Storage suggestions

    1. Store in a dry and clean room at room temperature.

    2. Do not approach sources of fire, heating, or direct sunlight.

    3. The storage period is generally 3-6 months. If it exceeds the storage period and passes the technical standard inspection, it can still be used.
